Product Details:
|
| Capacity: | 200,000~600,000tons Annually | Raw Material: | Hot Rolling Carbon Structure Steel, High Qulity Carbon Structure Steel And Low Alloy Steel Coil, Silicon Steel |
|---|---|---|---|
| Thickness Of Steel Strip: | 1.5~6.0mm | Width Of Steel Strip: | 700~1,350mm |
| Processing Speed: | 30~180m/min | Coil Weight: | Max.25tons |
| Technology: | Continuous Acid Pickling | Energy: | Water, Electricity, Steam |
| High Light: | Continuous Pickling Line steel process,SemiContinuous Pickling Line,Semi Continuous Pickling machine |
||
Excellence Continuous Pickling Line 1.5~6.0mm 700~1350mm
(pinck roll, bridle roll, vertical guide roller...)
«Regulations on designing energy-saving technologies for iron and steel enterprises»( YBJ51-86)
« Code for construction and acceptance of industrial pipelines»(GBJ235- 82)
« Basic identification colors and identification marks for industrial pipelines»( GB8231-87)
« General technical requirements for hydraulic systems»( GB3766-1983)
« Standards for quality inspection and evaluation of metallurgical mechanical equipment installation engineering »( YB9246-1992)
« General technical conditions for heavy machinery»(JB/T5000.1-1998)－(JB/T5000.15－1998)
« General technical conditions for hydraulic systems of heavy machinery»(JB/T6996-93)
« General technical conditions for pneumatic systems of heavy machinery»(JB/T7932-87)
«General specification for construction and acceptance of mechanical equipment installation» (GB50231-98)
«Specification for construction and acceptance of metallurgical mechanical equipment installation (steel rolling equipment) » (YB9249-92)
There is no royal road for development, no end for innovation. In the past we had achieved initial victory by making concerted effort. Today we stand on a new starting point, and more in need of your infinite care and support, we look forward to more cooperation and exchange with you.
We are committed to provide the highest quality, the most valuable products and the best service to our customers, to create development space for our staff by sustainable and healthy economy growth.
Continuous Acid Pickling Line
For continuous acid pickling line, the headand rear parts of two different coils shall be welded together, both entry andexit of process sections are equipped with accumulators to guarantee acontinuous operation. Generally when the annual capacity exceeds 700,000 tons,continuous picking line will be adopted.
.
| Annual Production Capacity | 700,000~2,000,000tons(depends on the needs of customer) |
| Raw Material | hot rolling carbonstructure steel, high qulity carbon structure steel and low alloy steel coil, silicon steel; |
| Thickness of steel strip | 1.5~6mm |
| Width of steel strip | 700~1350mm |
| Processing speed | 100-240m/min (dependon the needs of output) |
| Coil weight | Max. 25tons |
| Technology | continuous shallow troughturbulence acid pickling |
| Energy | Water, electricity, steam |
