Annealing Hot Dip Continuous Galvanizing Line Furnace 0.12-0.6mm 650-1350mm

Large Image : Annealing Hot Dip Continuous Galvanizing Line Furnace 0.12-0.6mm 650-1350mm

Product Details:

Place of Origin:	China
Brand Name:	JJRS

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	USD$1,000,000~USD10,000,000
Packaging Details:	Wooden box;
Delivery Time:	7-10 months
Payment Terms:	T/T, L/C
Supply Ability:	1-10set/year

Contact Now

Annealing Hot Dip Continuous Galvanizing Line Furnace 0.12-0.6mm 650-1350mm

Description

Application:	Building Material	Material:	Hot Rolled Coil, Cold Rolled Coil
Width:	650mm-1300mm	Thickness:	0.3mm-2.5mm
Zinc Coating:	30-300g/m2	Name:	Best Choice Continuous Hot Dip Galvanizing Line (metal Ss)
Keyword:	0.12~0.6mm*650~1350mm United States Steel	Type:	Continuous
Process:	Hot Dip	Material:	Steel Metal Ss Cs
Componet:	Entry Looper	Capacity:	250,000t/year
High Light:	Annealing Continuous Galvanizing Line , Annealing and galvanizing lines , dip galvanizing line

Best Choice Continuous Hot Dip Galvanizing Line for sale 0.12~0.6mm*650~1350mm

Entrance section:

1#(2#) Unwinding → 1#2#Cut Clip Feeding Stick → Convergence Clip Rolling → Welding Machine →

1# tension roller → chemical degreasing → alkali scrubbing → electrolytic degreasing → water scrubbing →1#Water rinse→2# water rinse→3#water rinse→hot air drying→

Process section:

2#tension roller→1#correction→inlet looper→2#correction→3# tension roller→measuring roller→annealing furnace→4# Heat tension roller→zinc pot→quick cooling section→air cooling→tower steering roller→horizontal air cooling→steering roller→water cooling→hot air drying→3#correction→lighting machine→stretching straightening machine→passivation→resistant Fingerprint coating machine→drying furnace→4#correction→export looper→

Exit section:

5# tension roller→oiling→outlet shearing pinch roller→steering pinch roller→EPC correcting coiler→inspection→packaging→warehouse

Name	Best Choice Continuous Hot Dip Galvanizing Line for sale 0.12~0.6mm*650~1350mm united states steel
Application	Building Material
Width	650mm-1350mm
Thickness	0.12mm-0.6mm
Capacity	200,000t/year
Zinc Coating	30-300g/m2

Component

entry looper etc.

Keyword	steel Continuous Galvanizing Line
Type	Continuous
Process	Hot dip
Coil Material	steel metal ss cs
Material	Hot rolled coil, cold rolled coil

Annealing Hot Dip Continuous Galvanizing Line Furnace 0.12-0.6mm 650-1350mm 0
