Hydrochloric Acid Regeneration Machine 3m3/H Acid Storage Tank Cutting Edge Tech

acid regeneration plant 3m3/h (acid storage tank) Cutting-edge technologe

For carbon and silicon steels

Fluidised bed acid regeneration facility
Spray roaster acid regeneration facility
For stainless steels

Main benefits:
Environmental protection through the recovery of hazardous chemicals;
Almost emission-free operation;
Recovery of costs through the sale of oxide as a high-quality co-product;
The highest processing speed on the market;
Optimised pickling owing to the consistency of operational parameters;
Independence from acid suppliers;
Rapid return on investment;
Compliance with current and future legal requirements regarding emissions;
Low maintenance costs;
Proven design;
Can be adapted to any type of pickling line.

Waste acid regenerating unit can be decomposited by wasteacid regeneration production line to obtain the regenerated hydrochloric acid andiron oxide powder with the same concentration as the original waste acidsolution not containing or containing a small amount of molysite. Regeneration acidafter concentration adjustment by complex acid could be used again by the acid picklingline.

Performance of the Acid Regeneration Line

Capacity: 3m³/h, 4m³/h, 6m³/h,8m³/h. Capacity can be designed according to client requirement.

Major Parameters

Waste acid Fe₂+≤140g/L HCL 3-5%

Regenerating acid Fe₂+ ≤5g/L HCL 190-220g/L

Iron powder Fe₂O₃≥99% CL-≤0.01%

Exhaust gas Fe₂O₃≤10mg/Nm³ HCL ≤20mg/Nm³

Effluent Fe₂+0-120g/L HCL 0-20% (discontinuously discharge)

Efficiency ≥99.5%

Energy consumption <750Kcal/L

Energy electricity, water, compressed air

Characteristics of the Acid Regeneration Line
Our waste acid regenerating unit could connect with the acid pickling lineseamlessly as we have taken into consideration of plant planning productionline design to commissioning, production and maintenance together. By our AcidRegeneration Line, the resource configuration optimization is realized, theuser cost is reduced, the operation is simplified, the efficiency is improved, andthe stable and safe operation of the line is guaranteed.
With the society environmental protection consciousness is strengthened, nowadaysmore requirements are raised for waste acid treatment. Our company waste acidregenerating unit adopts the advanced spray roasting method (i.e.: Ruthnermethod), so that the hydrochloric acid recovery efficiency is higher, "TheThree Wastes" emissions are less. Not only the problem of environmentalprotection is solved, but also very good social benefits and economic benefitsare honored.
