Product Details:
|
| Application: | Building Material, Home Appliances Panel, Automobile Panel, Can Material, Cover Material | Material: | Steel Metal |
|---|---|---|---|
| Width: | 1400mm | Thickness: | 0.16~0.6mm |
| Name: | Color Coating Line For Galvanized Sheet | Keyword: | Steel Strip Color Coating |
| Type: | Continuous | Process: | Hot Dip |
| Capacity: | 100,000~300,000ton/year | ||
| High Light: | color coating lines 1400MM,1400MM colour coating line manufacturers,1400MM galvanized sheet colour coating line |
||
30000 T/Y Color Coating Line equipment with technical supports
Steel Strip Color Coating Line / Material Galvanized sheet
0.16-0.6×1400MM Color coating production line
JJRS is professional on turn-key projects, from general planning, designing, to manufacturing, installing, commissioning and servicing. Besides, our business also covers single equipment’s designing, manufacturing and installing, as well as electric transmission, control system and spare parts. All basing on these supporting businesses, we mark out a developing strategy that taking metal strip intensive processing and color coating production lines as main, and the associated industry products as supplement.
Color coating line roll coater machine is an integrated product of mechanical and electrical control. The main body of the equipment can be configured with vertical type or horizontal type according to process requirement, also can be configured with two rolls or three rolls coating heads. Equipped with a pressure sensor to control the coating layer effectively.
Application Scope of Coaters for Color Coating Line
Material: Galvanized Sheet
Material Thickness: 0.16-0.6mm
Material Width: 1400mm
Line Speed: ≤210m/min
| Raw Steel type | Galvanized (Aluminium zinc) steel coil |
| Coil thickness: | 0,15-0.6mm |
| Coil width: | 1000-1250mm |
| Coil ID: | Ø 508mmmm/Φ610mm |
| Coil weight: | Max5t |
| Coil ID: | Ø 508mm/Φ610mm |
| Coil weight: | Max 5t |
| 1 | CPC centering machine V# | 1 |
| 2 | 2# steering roll | 2 |
| 3 | Finish Coating Room | 1 |
| 4 | Finish roller Coater | 1 |
| 5 | Finish curing oven | 1 |
| 6 | Incinerator system | 1 |
| 7 | Cold air blow device III# | 1 |
| 8 | Hot air blow device III# | 1 |
| 9 | Tension bridle roll V# | 1 |
