Product Details:
|
| Application: | Building Material, Home Appliances Panel, Automobile Panel, Can Material, Cover Material | Material: | Steel Metal |
|---|---|---|---|
| Width: | 914~1250mm | Thickness: | 0.18mm~0.5mm |
| Name: | Steel Strip Color Coating Line(Coating, Laminating, Printing Etc) | Keyword: | Steel Strip Color Coating |
| Type: | Continuous | Process: | Hot Dip |
| Capacity: | 300000ton/year | ||
| High Light: | continuous color coating line,color coating line equipment,colour coating line process |
||
Beijing JJRS Technology Development Co., Ltd. registered in national high tech park-Beijing Economic and Technological Development Zone, is high-tech enterprise specialized in the complete set of metallurgical equipments, intensive processing of steel strip and metal surface coating engineering project, with the integration of mechanism, optics, electric and hydraulic pressure.
JJRS is professional on turn-key projects, from general planning, designing, to manufacturing, installing, commissioning and servicing. Besides, our business also covers single equipment’s designing, manufacturing and installing, as well as electric transmission, control system and spare parts. All basing on these supporting businesses, we mark out a developing strategy that taking metal strip intensive processing and color coating production lines as main, and the associated industry products as supplement.
Raw material:GI/GL steel coil
Coil data:
Thickness: 0.18-0.5mm
Width:914-1250mm
Raw coil:
ID: Φ508mm
ED: MaxΦ1350mm
Weight: Max10000 Kg
| Material: | galvanized steel strip or common steel steel strip |
| Line speed: | whole line speed 40-150m/min |
| End product weight: | 3,500-15,000kg/coil |
| Outer Dia. of coil: | φ1350mm |
| Inner Dia. of coil: | φ508 |
| Thickness of steel strip: | 0.18-0.5mm |
| Width of steel strip: | 914~1,250mm |
| Energy: | produce gas/natural gas/blast furnace gas,steam and electricity |
| Thickness of color plate: | thickness of the frontsingle layer dry film can be adjusted between 10-20μm |
| Color plate quality: | comply with the requirement ofnational standard GB/T12754-2006 |
| Coiling staggered layer: | one side≤1.0 mm |
| thickness of the reverse single layer dry film can beadjusted between 5-10μm |
