Product Details:
|
| Material: | Cold Rolling Coil, Hot Rolling Acid Pickling Coil | Thickness: | 0.7~1.7mm |
|---|---|---|---|
| Width: | 400mm | Annual Output: | 120,000 Ton |
| Type: | Continuous | Coating: | Galvanizing, Painting, Plating, Hot Dip Galvanizing, Zinc Coat |
| After-sales Service Provided: | Engineers Available To Service Manchinery Overseas, Field Installation, Online Support | Name: | Continuous Galvanizing Line |
| Production Mode: | Double/single Work Line | ||
| High Light: | electrolytic galvanizing line,hot dip galvanizing plant 400mm,hot dip galvanizing plant 0.7-1.7m |
||
New Generation Steel Strip Continuous Annealing
Hot Dip Galvanizing (Aluminizing) Technology --- JJRS-Sendzimir
After cold rolling, the highly worked non-grain-oriented electrical steel strip (NGO) is recrystallized in a horizontal continuous furnace and the grain size is adjusted by secondary recrystallization. A thin layer of insulating lacquer is then applied in-line with a roller coater, in order to reduce eddy current losses in the electrical motor and prevent corrosion. The process steps for this phase of production are as follows:
Multi-stage strip cleaning
Rapid strip heating in the heating up section of the continuous furnace (optionally with rapid heating systems up to 500 K/s)
Option: decarburization to prevent magnetic aging
Annealing for recrystallization and discontinuous grain growth in process atmosphere
Controlled cooling in the slow cooling zone and final cooling zone
Coating by roller coater and drying in a floater furnace
Process simulation before heat treatment makes it possible to identify suitable annealing programs to achieve the specified magnetic and mechanical properties
Hydrogen regeneration units, which provide hydrogen savings of up to 50 %, are available
Technology Patent of " JJRS-Sendzimir"
The launch of " JJRS-Sendzimir" depends on a number of technology patents innovated by ourselves.
|
|
|
|
|
|
|
|
|
|
1. Steel coil printing line:
| material | Thickness | Width | Speed | Thickness of coating | Thickness of printing | Energy |
| GI, GL, Cold-rolled strip | 0.1-1.5mm | 500-1750mm | 30-180m/min | 5-30μm | ≤1μm(oil ink or polyester) | Gas, electricity, steam etc |
2. Aluminium coil printing line:
| material | Thickness | Width | Speed | Thickness of coating | Thickness of printing | Energy |
| Hot aluminium sheet, aluminium alloy | 0.2-3mm | 700-1850mm | 25-130m/min | Max40μm | ≤1μm(oil ink or polyester) |
Gas, electricity, steam etc |
