1550mm Coil Continuous Galvanizing Line Equipment For Steel Strip

1550mm Coil Continuous Galvanizing Line Equipment For Steel Strip
1550mm Coil Continuous Galvanizing Line Equipment For Steel Strip 1550mm Coil Continuous Galvanizing Line Equipment For Steel Strip

Large Image :  1550mm Coil Continuous Galvanizing Line Equipment For Steel Strip

Product Details:
Brand Name: JJRS
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: USD$1,000,000~USD10,000,000
Packaging Details: wooden box; plastic package
Delivery Time: 7-10months
Payment Terms: L/C, T/T

1550mm Coil Continuous Galvanizing Line Equipment For Steel Strip

Description
Application: Building Material, Home Appliances Panel, Automobile Panel, Can Material, Cover Material Material: Hot Rolled Coil, Cold Rlled Coil
Width: 500mm~130mm Thickness: 0.15mm~6mm
Zinc Coating: 30-300g/m2 Name: Galvalume Line
Keyword: Steel Galvalume Line Type: Continuous
Process: Galvalume Material: Steel Metal
Capacity: 200,000t/year
High Light:

1550mm Coil galvanizing line equipment

,

Coil Continuous galvanizing line equipment

,

Galvalume plant

Valued 1550mm Coil Continuous Galvanizing/ Galvalume Line for Steel Strip



Beijing JJRS Technology Development Co., Ltd. registered in national high tech park-Beijing Economic and Technological Development Zone, is high-tech enterprise specialized in the complete set of metallurgical equipments, intensive processing of steel strip and metal surface coating engineering project, with the integration of mechanism, optics, electric and hydraulic pressure.



JJRS assembles excellent technology research team, high qualified management personnel, perfect management system and powerful engineering design and complete project capability. As an integrated solution provider, we are willing to provide iron and steel enterprises of all over the world with highest quality products and services, from general engineering contracting, integrated production lines, to single equipment, even components and spare parts.



Brief Introduction of 0.1~2.5mm*650~1350mm Continuous Galvalume Line

The continuous galvalume line is used to produce high quality galvalume steel sheets, it can realize the recrystallization annealing of cold rolled steel strip and deposit an equal thickness coating on the surface.



Process Flow

Main equipments according to processflow in turn are as follows:



Manually loading → entry skid → coil loading trolley I# & II# → pay off reel I# & II# → decoiling pinch rollI# & II# → transverse shearer I# & II# → join pinch roll → welder →riveter → roller leveler → tension bridle roll I# → entry accumulator → CPC double-roller centering machine I# → tension bridle roll II# → pre-degreasing →degreasing → washing I# → washing II# → purified water washing → hot air blowing device → chemical coating machine → chemical coating drying furnace →cold air blowing device → CPC double-roller centering machine II# → tension machine III# → base coating roller coater → base coating leveling chamber →base coating curing furnace → cold air blowing device → base coating forced cooling chamber → squeezing centering machine → hot air blowing device → tensionbridle roll IV# → CPC single roller centering machine I# → finishing coatingroller coater I# → finishing coating roller coater II# → leveling chamber → finishingcoating curing furnace → cold air blowing device → finishing coating forced cooling chamber → squeezing centering machine → hot air blowing device → tensionbridle roll V# → CPC double-roller centering machine III# → three color printing unit →printing thermal curing systemtensionbridle roll VI# → finishing roller coater → finishingleveling chamber → finishing curing furnace → hot laminating machine →finishing forced cooling chamber → squeezing centering machine → hot airblowing device → tension bridle roll VII# → cold laminating machine → exit accumulator→ CPC double-roller centering machine IV# → tension bridle roll VIII# → pinch shearer → exit pinch roll I# & II# → recoiler I# & II# (EPC) → coilunloading trolley I# & II# → auxiliary recoiler I# & II# → exit skid →manually unloading



Raw Material
Cold Rolled Hard Coil
Thickness
0.1-2.5mm
Width of Strip Steel
650-1350mm
Coating Weight
60-275g / M2 (Double-Side)
Internal Diameter of Steel Coil
508mm, 610mm
Outer Diameter of Steel Coil
900mm -2000mm
Steel Coil Weight
Max 25t
Product Level
Cq, Dq, Ddq
Energy Type
Natural Gas, LPG, Electricity
Installation
Provided
Specification
Customized
Trademark
JJRS
Origin
Beijing, China










1550mm Coil Continuous Galvanizing Line Equipment For Steel Strip 01550mm Coil Continuous Galvanizing Line Equipment For Steel Strip 11550mm Coil Continuous Galvanizing Line Equipment For Steel Strip 21550mm Coil Continuous Galvanizing Line Equipment For Steel Strip 3
